Dry Compressing Vacuum Pumps

Description

1. ECODRY plus

Dry Multistage Roots Vacuum Pumps

The ECODRY plus is a newly developed family of dry-compression multi-stage Roots vacuum pumps, which sets new standards in noise reduction. The pumps have been specially designed for use in quiet and clean environments, such as analysis and research laboratories. ECODRY plus provide clean vacuum at maximum pumping speeds of 40 and 55 m³/h while creating the lowest noise level technically possible. They deliver stable vacuum performance for many years without maintenance.

2. DRYVAC

The DRYVAC is a new family of dry compressing vacuum pumps. Depending on the application the pumps are available with various equipment components. The DRYVAC series specially is developed for photovoltaic, display and process industry applications. All versions of the DRYVAC family are water cooled, very compact and can simply be mounted to various vacuum systems, so particularly with regard to the well-proven RUVAC WH, WS and WA series.

3. CLAWVAC – Dry Rough Vacuum Pump

The new benchmark in rough vacuum

The CLAWVAC’s unique product features offer great advantages for the rough vacuum field. The pumps design enables extreme robustness, especially for challenging applications which include handling of particle and vapor contaminated gases. The user will experience a trouble-free and cost-saving operation.

4. SCROLLVAC plus

Oil-free Scroll Vacuum Pumps

Completely oil-free vacuum pumps for use in diverse applications. From analytical processes like surface analysis or electron beam melting. Also suitable as backing pump for turbomolecular systems.

5. SCREWLINE SP

SCREWLINE vacuum pumps are dry compressing backing pumps, the operation is based on the screw principle. Besides the integrated oil cooling arrangement for the rotors, the standard versions of the SCREWLINE pumps are air-cooled from the outside. For operation in air conditioned rooms a water-cooled version is offered. The portfolio is completed through ATEX-certified variants.

6. LEYVAC

LEYVAC vacuum pumps are dry compressing fore vacuum pumps, the operation is based on the screw principle. The LEYVAC series is especially developed for process industry, F&P, coating and display applications. They can simply be assembled by adapters to various vacuum systems, so particularly with regard to the well-proven RUVAC WH700 and WS(U) and WA(U) series.

7. DIVAC

Diaphragm Vacuum Pumps

This range of vacuum pumps was especially developed for laboratory operations and as backing pumps for (wide range) turbomolecular vacuum pumps. The DIVAC line is the logical continuation of diaphragm pump technology which has proven its quality in decades of service.

• • DIVAC Three Stages Diaphragm Vacuum Pumps
    • The DIVAC 1.4 HV3C is a three-stage diaphragm pump capable of resisting chemicals and offering an improved pumping performance. Its speed is infinitely variable from 700 to 1600 rpm so that he pumping speed of the pump can be easily adapted to differing requirements.
  • DIVAC L Two Stages Diaphragm Vacuum Pumps
    • DIVAC L dual stage DIVAC L diaphragm pumps are suited for almost all requirements in the chemistry lab. They are basically corrosion and solvent resistant since their parts in contact with the pumped medium are made of PTFE (Teflon), FFPM (Kalrez) and PVDF (Solef).
  • DIVAC Backing Pumps for Turbomolecular Pumps
    • The dry compressing DIVAC diaphragm pumps were developed for laboratory operations It satisfies the highest expectations in terms of precision, reliability and ease of use.
